Scrap Motor Recycling Machine for Used Motor Waste Rotor Stator Copper Winding Dismantling

Ask Lasest Price
Supply Ability :	60 Set/Sets per Month
Price :	negotiable
Brand Name :	PAIBO
Delivery Time :	35

Add to Cart

Product Details
Company Profile

Scrap Motor Recycling Machine for Used Motor Waste Rotor Stator Copper Winding Dismantling

Scrap Motor Recycling Machine Copper Wire Dismantling Machines

The waste motor dismantling machine and motor copper extraction machine solve the problem of recycling waste motor rotors and coils.

Motor stator recycling machine is designed to recover the copper wire in various scrap motor stators. The machine can efficiently dismantle various scrap motor stators with the diameter of 6cm-50cm. By using motor stator recycling machine, copper wires and silicon steel case can be recycled efficiently, greatly improving economic benefits.

Machine Model:	PB-M 2
Dismantling range diameter	Below 50cm
Dismantling range inner diameter	More than 4cm
Motor power:	4kw
Working voltage:	380V
weight:	550kg
Machine size:	2.7×0.75×1.1m

Copper Cutting Machine & Copper Pulling Machines:

Motor stator recycling machine consists of two machines, copper wire cutting machine and copper wire pulling machine. Copper wire cutting machine is used to cut one end of copper windings in the motor stator, while copper wire pulling machine is used to pull copper windings out of the motor stator.

How to Operate Motor Stator Recycling Machine?
In order to recover the copper wire from motor stator, first you have to use copper wire cutting machine to cut one end of copper winding. Then put the cut motor stator on the lifting platform of copper wire pulling machine and let it rise to the batter board through switch button. After motor stator is well positioned, use the tongs of the pulling machine to drag out the copper wire.

APPLICATION

the motor disassembling machine mainly purchase and use for waste material recycling companies,The motor disassembly machine will carry out a series of disassembly operations on the discarded and burned out motors that will not be in normal use.The second is the heavy equipment in the industrial plant and mine motor, the load is too large, the body temperature is too high, resulting in the normal use of the motor;The third is the motor manufacturing factory, in the process of production there are some defective, unqualified, not up to standard, not normal factory motor;The motor disassembly machine can be used to quickly pull out the copper wire inside the stator, effectively achieving the purpose of separating copper and iron. At the same time, the silicon steel sheet can be returned to the production line for recycling, and the scrap copper can be returned to the copper factory to enter the market as a new product.electrical dismantling equipment electric waste motor recycling machine for sale

Motor stator processing range: 50-500mm. Raw materials: Motor stators for household appliances, such as refrigerators, cold drink machines, air conditioners, air fans, air dehumidifiers, etc., washing machines, electric irons, dust collectors, rice cookers, microwave ovens, electric ovens, electric hair dryers, TVs, radios.
